• Efficient 20 W RGBW LED
• IP67 and IK08 classification for permanent outdoor use
• 4 sizes to fit any application
• 6° beam angle
• Various filters for different beam angles available as accessories
• Filters can be applied without breaking IP Seal
• Anti glare shield included for less light spill
• Calibrated LEDs for excellent colour consistency
• Control via DMX, RDM or external control remote (UNICON)
• Minimum LED lifetime: 50,000 hours (to >70% luminous output)
| • Product type: | LED Lighting |
|
• Type: | Installation spotlights |
|
• Colour spectrum: | RGBW |
|
• Number of LEDs: | 20 |
|
• LED type: | 4in1 chip |
|
• LED power: | 20 W |
|
• Luminous flux: | 11000 lm |
|
• LED PWM Frequency: | 650 Hz, 1530 Hz, 3600 Hz, 12000 Hz, 18900 Hz, 25000 Hz |
|
• Half spread angle: | 6 ° |
|
• Tenth dispersion angle: | 11 ° |
|
• DMX In/Out: | Permanently mounted 5-pin signal cable (DMX In and Out), 2 m, open ends |
|
• DMX Functions: | Calibration, CCT, Colour presets, Device Settings, Dimmer 8bit/16bit, Dimmer Curve, Dimmer Response, Factory reset, PWM, Record User Colour, RGBW, Strobe |
|
• Control: | DMX512, RDM |
|
• Standalone Functions: | Auto programs, CCT, Colour presets, Direct, Timer |
|
• Controls: | External Control Remote (UNICON) |
|
• Operating voltage: | 100 V AC - 240 V AC, 50 - 60 Hz |
|
• Colour rendering index (Ra): | >79 @ 8700K |
|
• power factor: | >0,9 / 100-240V |
|
• Power connector: | Permanently mounted mains cable H07RN-F, 3x 1.5 mm², 2 m, open ends |
|
• Overvoltage protection: | 4 KV |
|
• Ambient temperature (operating): | -20 - 45 °C |
|
• Relative Humidity: | < 80%, not condensing |
|
• Housing material: | Die-cast aluminium |
|
• Cabinet colour: | Black |
|
• Corrosion resistance: | C5-M powder coating |
|
• Protection class: | IP67 |
|
• Cable ducts: | IP68 |
|
• Impact resistance level: | IK08 |
|
• Housing Cooling: | forced air cooling |
|
• Max. Mounting height: | unlimited |
|
• Height: | 443 mm |
|
• Width: | 423 mm |
|
• Depth: | 285 mm |
|
• Weight: | 19,31 kg |
|
• Accessories (included): | Half anti glare shield, Mounting ring for optional interchangeable lenses |
|
• Accessories (optional): | External Co |
ntrol Remote (UNICON), Full anti glare shield, Interchangeable lenses (20°, 40°, 55°, 60°x10°)
