Features
25000 lumens – Excellent light quality with a very flat and uniform field
|
1: | 5 zoom – Fast zoom with auto-linked focus |
Fat beam front lens – The 140 mm front lens exceeds the size of any other fixture in this segment for just the right fat beam look
5 + 5 rotating gobos – All glass gobos with optimal focal separation for superior morphing effects
Effect wheel – Patent-pending effect wheel provides an additional 4 fixed gobos and 135° animation effect
CMY – Vibrant color mixing with a superior palette of colors including true reds, rich ambers, primary green and deep blues
8-slot color wheel – Fixed colors for added color choice
Linear CTO – Daylight to tungsten CCT control and expansion of the CMY palette
Dimmer and shutter – All-in-one dimmer and shutter system for instant blackout or smooth fades
Iris – Fast and tight iris with adjustable dynamic effects
Strobe – Diverse strobe effects using mechanical or electronic control or in combination
Soft frost – A light frost leaves gobo artwork visible with a beautiful soft edge. Includes a linear focus blurring option
4-facet prism – Real beam separation with rotation and index control for dynamic effects and accurate tiling
Physical
|
Length (Head): | 566 mm (22.3 in.) |
|
Width: | 471 mm (18.5 in.) |
|
Width (Base): | 335 mm (13.2 in.) |
|
Height (head straight up): | 709 mm (27.9 in.) |
|
Height (maximum): | 726 mm (28.6 in.) |
|
Weight: | 36 kg (79.4 lbs.) |
Lamp
|
Type: | 1000 W short-arc discharge |
|
Color temperature: | 6000 K |
|
CRI (Color rendering index): | Approx. 80 |
| Average lifetime: | 750 hours |
|
Hot restrike: | Semi-hot (restrike in under 90 seconds) |
|
Socket: | PGJ50 |
|
Ballast: | Electronic |
Dynamic Effects
|
Color mixing: | CMY, independently variable 0 - 100% |
|
Color temperature control: | CTO, variable 6000 - 3200 K |
|
Color wheel: | 8 interchangeable dichroic filters + open, indexing, continuous rotation, random color |
|
Aerial gobo wheel: | 5 interchangeable aerial effects + open, indexing, continuous rotation and shake |
|
Breakup texture/gobo wheel: | 5 interchangeable texture/breakup gobos + open, indexing, continuous rotation and shake |
|
FX wheel: | Interchangeable static gobo and gobo animation effects |
|
Prism: | Interchangeable 4-facet rotating prism |
|
Iris: | 0 - 100%, pulse effects |
|
Frost: | Frost filter |
|
Mechanical dimmer: | 0 - 100%, choice of four dimming curves |
|
Mechanical shutter: | Strobe effect 2 - 10 Hz, pulse effects, instant open and blackout |
|
Pre-programmed effects: | Two ranges of FX, independent or combined |
|
Focus: | 2 m (6.6 ft.) to infinity |
|
Zoom: | 10° - 44° |
|
Zoom-focus linking system: | 3-zone |
|
Pan: | 540° |
|
Tilt: | 268° |
|
Position correction system: | Absolute position monitoring |
Control and Programming
|
DMX channels: | 26/33 |
|
Setting and addressing: | Control panel with backlit graphic display and jog wheel or via DMX |
|
16-bit control: | Aerial, breakup and texture effect rotation and indexing, focus, zoom, pan and tilt |
|
DMX compliance: | USITT DMX512-A |
|
RDM compliance: | ANSI/ESTA E1.20 |
|
Receiver: | Opto-isolated RS-485 |
|
Firmware update: | USB memory device or USB/DMX hardware interface over DMX link |
Service Utilities
|
Fixture identification: | User-settable fixture ID number |
Construction
|
Color(s): | Black |
|
Housing: | UV-resistant fiber-reinforced composite |
|
Reflector: | Glass, cold light |
|
Protection rating: | IP20 |
Installation
|
Mounting points: | Eight quarter-turn locking points |
|
Orientation: | Any |
|
Minimum distance to illuminated surfaces: | 1.6 m (5.2 ft.) |
|
Minimum distance to combustible materials: | 0.3 m (1.0 ft.) |
Connections
|
AC power input: | Neutrik PowerCon connector with 3 m (9.8 ft.) cable tail |
|
DMX and RDM data in/out: | 5-pin locking XLR |
|
USB memory devices: | USB host socket |
Electrical
|
AC power: | 120-240 V nominal, 50/60 Hz |
|
Power supply unit: | Auto-ranging electronic switch-mode |
Typical Power and Current
|
120 V, 60 Hz: | 1225 W, 10.3 A, PF 0.999 |
|
208 V, 60 Hz: | 1190 W, 5.8 A, PF 0.996 |
|
230 V, 50 Hz: | 1186 W, 5.2 A, PF 0.994 |
|
240 V, 50 Hz: | 1194 W, 5.0 A, PF 0.993 |
