• Controlled Beam and SOFT White Source, ideal for multiple camera use in the studio
• Beautiful even distribution and a real quality projection with precise reference white
• NO PIXEL EFFECT from the LED and contained size
//Either Remote Phosphors Panel (interchangeable for Tungsten
Or Daylight)
// Rugged and Lightweight Aluminium extrusion housing with Black Oxidation low glare finishing
// DeSisti SoftLED 1 is available with D Track (Data/Power) adapters
// High efficiency, silent passive heat management.Thermal stabilization of the LED operating temperature is managed by an internal thermal sensor and CPU, variable fan speed and heat sink to maintain the LEDs at optimal constant temperature
// DMX (or local) control of the Light intensity from 0 to 100% with smooth transition and theatrical quality dimming….flicker free at any dimming level
// 100% flicker free system with universal Power Supply unit v90-250V to work in every condition and frame rate.
// The accessories are secure regardless of the orientation of the fixture. Accessories have been designed for one hand installation.
// Available with either positive lock manual yokes for comfort and ease of handling, or pole operated yokes which can be used via the lighting pole for Panning and Tilting the lights as well as manually, since the mechanical activators are equipped with clutches
// Honeycombs and intensifier accessories work perfectly to shape and control the beam spread.
DESCRIPTION VALUEVAL
Power to LED 180W
Flicker Free - DC Current
Voltaggio & PFC 90-250V 50-60Hz PFC 0,96
Rated Voltage & PFC 200W @ 230V
205W @120V
Power Connection powerCON IN & OUT
DMX Data linkUSITT DMX512-A 5-pin XLR for DMX in & out.Use shielded data cables.Do not overload the daisy chain. Up to a maximum of 32 devices can be used on a single DMX chain
DMX Channels 1 @ 8bit
2 @ 16bit
LED BOARDS Lifetime 50.000 hours with 70% Lumen Maintenance
CCT T: 3.200°K
D: 5.600°K
CRI / TLCI T: 96 / 96
D: 96 / 96
Protection Type IP 22
Weight of Fixture M.O. 5,5 kg. (12.1 lb)
P.O. 6,7 kg. (14.8 lb)
Max. Housing Surface
Temperature 70° C
