ROSCO Supergel
Sortiment vysokoteplotných (HT) farebných filtrov so spomaľujúcim horením od spoločnosti Rosco
Supergel je považovaný za jeden z najpoužívanejších radov farebných filtrov na svete. Pozostáva z viac ako 75 farieb a 15 difúzií.Tieto fitre ponúkajú dlhú životnosť pred horúce svetlá pre divadlá,kiná TV a film.Jedinečný výrobný proces poskytuje Supergelu neprekonateľnú tepelnú odolnosť, farebnú stálosť a nehorľavosť.
• Základ: Polykarbonát (s prísadou spomaľujúcou horenie)
• Hrúbka: 3-4 mil (75-100um) nominálne
• Maximálna šírka: 61 cm
• Hodnotenia spomaľujúce horenie: M1, B1, C1, BS3944 PART 1 1992, NFPA 701
• Súlad: RoHS, REACH,
• Maximálna teplota:
- Zmäkčenie: 160 °C
- Topenie: 220 °C
Čísla produktov
• 100 9XXXX 2024 Supergel 20" x 24" (50 cm x 60 cm) hárky
• 100 9XXXX 2425 Supergel 24" x 25" (60 cm x 7,62 m) rolky
Rosco’s range of high-temp (HT), flame-retardant color filters
Supergel is regarded as one of the most widely used color filter ranges in the world. It is comprised of more than 75 colors and 15 diffusions that are engineered using Rosco’s exclusive body-colored, polycarbonate extrusion process to offer the longest possible life under hot theatrical and film/TV light fixtures. This unique manufacturing process also provides Supergel with unsurpassed heat-resistance, color-stability and flame-retardancy.
Supergel features Rosco’s distinctive body-colored extrusion process. The manufacturing of these filters begins by combining powdered resin and dyes to create a concentrated color “pellet.” This concentrated colorant and additional clear resin are then fed into an extruder where they are blended together under intense pressure and heat. The mixture is then pushed through a die, which forms it into body-colored, 24” (60cm) wide film.
• Base: Polycarbonate (with fire retardant additive)
• Gauge : 3-4 mil (75-100um) nominal
• Max Width: 24in (61cm)
• Flame Retardant Rating: M1, B1, C1, BS3944 PART 1 1992, NFPA 701
• Compliance: RoHS, REACH, Proposition 65
• Max Temp:
- Softening: 320°F (160° C)
- Melting: 425°F (220° C)
Product Numbers:
• 100 9XXXX 2024 Supergel 20"x24" Sheets (50cm x 60cm)
• 100 9XXXX 2425 Supergel 24" X 25' Rolls (60cm x 7.62m)
