LD Systems X 223 - Aktívny crossover
LD Systems X223 je stereo 2 -pásmový / mono 3 -cestný crossover v štandardnom rackovom formáte 19 " / 1U. Jeho robustná konštrukcia, vysoko kvalitné a robustné gombíky a integrovaná napájacia jednotka sú v tejto cenovej kategórii vzácnosťou. Poskytuje mono subvýstup, nastaviteľnú crossover frekvenciu pre každý kanál, nastaviteľné LF/HF a vstupné zisky, ovládanie reverznej fázy, prepínateľné 40 Hz High-Pass filtre a symetrické XLR vstupy a výstupy. S LD Systems X 223 získate crossover spĺňajúci profesionálne štandardy a ponúkajú vynikajúcu kvalitu a zvukové vlastnosti.
• Šírka 482 mm
• Výška 44,5 mm
• Hĺbka 153 mm
• Hmotnosť 2,6 kg
The LD Systems X223 is a stereo 2 way/mono 3 way crossover in standard 19"/1U rack format. Its rugged construction, high quality and robust knobs as well as integrated power unit are rarities in this price range. It provides a mono sub-output, an adjustable crossover frequency for each channel, adjustable LF/HF and input gains, phase reverse controls, switchable 40 Hz High-Pass filters and symmetrical XLR In- and Outputs. With the LD Systems X223 you get a crossover fulfilling the professional standards and offering great quality and sound characteristics.
• PRODUCT TYPE: Signal Processors
• VERSION: 2-way stereo/3-way mono
• FREQUENCY RESPONSE: 20 - 20.000 Hz
• DYNAMIC RANGE: 106 dB
• SIGNAL-TO-NOISE RATIO: > 93 dB
• TOTAL HARMONIC DISTORTION (THD):< 0.004 %
• CROSSTALK: < - 80 (20 - 20.000 Hz) dB
• MAX.INPUT LEVEL: +21 (balanced or unbalanced) dBu
• MAX.OUTPUT LEVEL: +21 (balanced or unbalanced) dBu
• INPUT IMPEDANCE: 50000 kOhm
• OUTPUT IMPEDANCE: 200 Ohm(s)
• CONTROLS: 2 x crossover frequency low/high, 2 x crossover low/mid, 2 x high gain, 2 x highpass (40 Hz), 2 x input gain, 2 x low gain, 2x frequency switch x1/x10, 4 x inv switch, LF sum, Mono/stereo mode
• IINDICATORS: 2 x clip, 2 x crossover x 10, 2 x highpass, 4 x inv., mono, stereo
• INE INPUTS:2
• LINE INPUT: connectors XLR
• LINE OUTPUTS: 4
• LINE OUTPUT: connectors XLR
• MAIN CONNECTORS: IEC socket
• OPERATING VOLTAGE: 220 V AC - 240 V AC
• WIDTH: 482 mm
• HEIGHT: 44.5 mm
• DEPTH: 153 mm
• WEIGHT: 2,6 kg
