Four balanced microphone inputs with high-quality preamplifiers, mono compatible stereo channels, an integrated compressor and 100 digital effects with 24-bit resolution turn the VIBZ 8 into a flexible sound control unit.
The microphone channels are switchable to line level and are equipped with high-quality preamplifiers and a reduction in bass; two of them also feature inserts for individual signal processing. For an effective sound adjustment, the VIBZ 8 has very precise 3-band EQs with practical selectable mids.
The master section of the mixer features an effects loop, adjustable monitor outputs and a headphone jack. The VIBZ 8 also has inputs and outputs for recording and playback devices, is extremely easy to use and impresses with its transparent and detailed sound. It is ideal for small bands, installations, home recording, and for use as a sub-mixer.
It comes with an external power supply that can be tightly secured to the mixer. A foot switch for the effects section and an adapter for mounting the VIBZ 8 on microphone stands are available as accessories.
• Product type: Mixers
• Type: Live
• Channels: 8
• Mono Mic and Line Input Channels: 4
• Stereo Line Input Channels: 3
○ MAIN SECTION:
• AUX / Effects Send Channels: 1
• AUX / Effects Send Connectors: 6.3 mm stereo jack unbalanced
• Stereo AUX Return Channels: 1 x stereo
• Stereo AUX Return Connectors: 2 x 6.3 mm TRS
• Stereo Tape Out Channel: 1 x stereo
• Stereo Tape Out Connectors: 2 x RCA (Cinch)
• Stereo Tape In Channel: 1 x stereo
• Stereo Tape In Connenctors: 2 x RCA (Cinch)
• Unbalanced stereo Main Outputs: 1
• Unbalanced stereo Main Output Connections: 6.3 mm TRS
• Unbalanced Stereo Main Out Impedance: 120 Ohm(s)
• Max. Unbalanced Stereo Main Out Level: 20 dBu
• Stereo Control Room Out: 1
• Stereo Control Room Out Connectors: 6.3 mm TRS
• Headphones ouput: 1
• Headphones outputs: 6.3 mm TRS
• Digital Effects Processor: Yes, 24-bit AD/DA Resolution
• Number of Presets: 100
• Footswitch Connector DFX Mute: 6.3 mm TRS
• Main section controls: DFX Mute Schalter, DFX Presets, DFX To Main Volume, Master Volume, Phantom Power, Phones / Control Room Volume, Stereo Return Volume
• Indicators: 8-segment Level Meter, Channel Peak, DFX Peak / Mute, Phantom Power, Power
• Power supply: 18V DC - 1 A, External PSU, 230 V
• Width: 265 mm
• Height: 78 mm
• Depth: 352 mm
• Weight: 2,3 kg
