This passive 2-way loudspeaker has been designed as a companion to the active MIX 6 A G3 for small-scale PA and personal monitoring applications. It features the same 10" custom woofer and 1" HF driver complement, 80 Hz to 20 kHz frequency response and 80° x 70° dispersion delivering crystal clear sound with punch and detail.
The rigid MDF enclosure features two 16 mm pole mounts for horizontal or vertical orientation. In a master-and-follower setup with the active unit, the MIX 6 G3 provides amazing performance and versatility in a lightweight, easily portable package.
• Product type: PA loudspeaker
• Type: passive
• Low/mid Woofer dimensions: 6.5 "
• Woofer dimensions: 165.1 mm
• Woofer brand: Custom-made
• HF driver dimensions: 1 "
• HF driver dimention: 25.4 mm
• HF driver brand: Custom-made
• Dispersion (H x V): 80 x 70 °
• Load rating (RMS): 70 W
• Peak power: 280 W
• Frequency response: 80 - 20.000
• SPL (1W/1m): 90 dB
• Max. SPL: 117 dB
• Impedance: 4 Ohm(s)
• Protection circuits: ICL (Intelligent Clip Limiting), over-current, overload, Short circuit, thermal overload
• Loudspeaker inputs: 1
• Speaker input connections: 6.3 mm jack
• Loudspeaker outputs: 6.3 mm jack
• Cabinet material: MDF
• Cabinet surface: texture paint
• Cabinet construction: Bass Reflex
• Width: 214 mm
• Height: 323 mm
• Depth: 221 mm
• Features: 2 x 16 mm pole mount socket
• Weight: 4,4 kg
